2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine

2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine

  • High Light

    2.2KW Thermal Paper Slitting Machine

    ,

    120m/min Thermal Paper Slitting Machine

    ,

    Credit Card paper roll making machine

  • Certification
    CE, ISO9001, BV, ISO,slitting Rewinding Machine
  • Type
    Paper Slitting Machine
  • Condition
    New
  • Overall Dimension
    2500*1600*1600mm
  • Weight
    1.9 Tons
  • Application
    ATM Roll, Receipt Roll, Cash Roll
  • Warranty
    1 Year
  • Packing
    Wooden Box
  • Voltage
    380V, 220V
  • Working Speed
    120m/min
  • Function
    Slitting Rewinder, Slitting Rewinding JUMBO Paper Roll
  • Power
    2.2 KW
  • After-sales Service
    Engineers Available To Service Machinery Overseas/Online Support/Video Technical Support
  • Product Name
    Slitter Rewinder Machine Paper Roll Cutting/slitting Machine/label Slitting And Rewinding Machine
  • Color
    Silver Or Gray
  • Precision
    ±0.1mm
  • Max.rewind Diameter
    180MM
  • Max Unwinding Diameter
    1100-1400mm
  • Place of Origin
    China
  • Brand Name
    FOCUS
  • Model Number
    900mm
  • Minimum Order Quantity
    1 set
  • Price
    16000usd per set
  • Packaging Details
    wooden box
  • Delivery Time
    20-30 days
  • Payment Terms
    L/C, D/A, D/P, T/T
  • Supply Ability
    50 sets per month

2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine

2.2KW Thermal Paper Roll Making Machine For Credit Card/POS Paper







DESCRIPTION



FOCUS brand Thermal paper slitting machine and printing machine is one of the advanced equipment used for slitting and printing thermal paper, cash register paper, ATM Paper and other paper less than 250gsm. It is flexo printing and slitting, automatic paper-cutting, automatic magnetic powder tension control, touch screen operation data setting and PLC program control, frequency conversion speed regulation and full pneumatic operation, accurate cutting, good printing effect and reliable performance.





Technical Data



Items Parameters
Max. Parent Web Width 900mm
Max. Parent Web Diameter 1000mm
Max. Rewinding Diameter 160mm
Frequency Inverter Motor 2.2Kw
Thickness Range 50-400gsm
Max. Machine Speed 120m/min
Overall dimension 4000*1700*1600mm
Weight 1900kg
Voltage 3 Phase 220V 60HZ or 380V 50HZ





It adopts Siemens frequency inverter for speed adjusting, the speed can be displayed on the operation panel. Frequency inverter motor: 2.2Kw. Automatic lift-up loading system is controlled by a motor from Taiwan (only for one ply slitting machine). All transmission rollers have been dynamic/static balance treated. Equipped with Auto length counter. The machine will stop when the length achieves the input data.



2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 02.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 12.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 2









APPLICATION

Thermal Paper POS Roll

Thermal Paper ATM Roll

2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 3



2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 4


2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 5



MACHINE PACKING AND TEST RUNNING OF THERMAL PAPER COATING MACHINE



Packaging Details


The normal package is wooden box. The wooden box will be fumigated. If container is too tigher, we will use pe film for packing or pack it according to customers special request



2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 62.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 7





2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 8




WHY CHOOSE US



This machine has the features of simple operation and high degree of automation. All parameters are adjusted to the best condition before leaving the factory. The only thing you need to do is to input the data of speed and tension, then the whole machine can be automatically and simultaneously controlled. This machine of our brand has been exported to more than 50 countries and has a good reputation all over the world.



1. Professional Siemens quality control system

2. Simple and easy to use operation

3. High degree of automation

4. Check key projects

5. More than 20 years experience

6. Double working station

7. Affordable price and good quality

8. High capacity, low consumption





2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 9


2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 10

COMPANY INFORMATION
2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 11

SUCCESSFUL MACHINE PROJECTS

2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 122.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 13



THERMAL PAPER COATING MACHINE PRODUCTION PROCESS

2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 14



2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 15

CUSTOMER FEEDBACK

2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 16
CERTIFICATE
2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 17

FOCUS attends more than 15 exhibitions of carbonless paper/thermal paper/paper coating machine every year all over the world to meet and service clients face to face.
2.2KW 120m/Min Thermal Paper Slitting Machine Credit Card Paper Roll Making Machine 18


Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
