Automatic Multichannel Label Cutting Machine for Thermal Paper Slitting
-
Highlight
Automatic Thermal Paper Slitter
,Multichannel Label Cutting Machine
,Thermal Paper Slitting Equipment
-
Max. Parent Web Width900mm
-
Max. Parent Web Diameter1000mm
-
Max. Rewinding Diameter2.2Kw
-
Thickness Range40-400gsm
-
Max. Machine Speed200m/min
-
Overall Dimension1600*1700*1600mm (1 Ply)
-
Weight1900kg
-
Voltage3 Phase 220V 60HZ Or 380V 50HZ
-
Machine TypeFlexo Letterpress Printing Machine
-
Overall Dimension4000*1700*1600mm
-
Power Supply220V/50Hz
-
Max. Unwinding Diameter1000mm
-
Cutting Accuracy±0.1mm
-
Rewind Diameter160mm
-
Slitting Accuracy±0.1mm
-
Place of OriginChina
-
Brand NameFOCUS
-
CertificationSGS, FSC，ISO
-
Model NumberFM25PSM0412001
-
Minimum Order Quantity1
Automatic Multichannel Label Cutting Machine for Thermal Paper Slitting
| Attribute | Value |
|---|---|
| Max. Parent Web Width | 900mm |
| Max. Parent Web Diameter | 1000mm |
| Max. Rewinding Diameter | 2.2Kw |
| Thickness Range | 40-400gsm |
| Max. Machine Speed | 200m/min |
| Overall dimension (1 Ply) | 1600*1700*1600mm |
| Weight | 1900kg |
| Voltage | 3 Phase 220V 60HZ or 380V 50HZ |
| Machine Type | Flexo Letterpress Printing Machine |
| Overall Dimension | 4000*1700*1600mm |
| Power Supply | 220V/50Hz |
| Max. Unwinding Diameter | 1000mm |
| Cutting Accuracy | ±0.1mm |
| Rewind Diameter | 160mm |
| Slitting Accuracy | ±0.1mm |
Designed for precision and ease of use, the FOCUS Thermal Paper Slitting System is perfect for a variety of paper materials, including thermal paper, NCR paper, and fax paper. It is capable of slitting materials up to 250gsm in thickness and is especially suited for creating small rolls of multi-layer paper. The user-friendly interface allows for quick setup and automatic management of slitting parameters once speed and tension are entered. Renowned for its reliability and efficiency, the FOCUS Thermal Paper Slitting System is a top choice in global markets.
| Item | Parameter |
|---|---|
| Max. Parent Web Width | 900mm |
| Max. Parent Web Diameter | 1000mm |
| Max. Rewinding Diameter | 200mm |
| Frequency Inverter Motor | 2.2Kw |
| Thickness Range | 40-400gsm |
| Max. Machine Speed | 200m/min |
| Overall dimension (1 Ply) | 1600*1700*1600mm |
| Weight | 1900kg |
| Voltage | 3 Phase 220V 60HZ or 380V 50HZ |
Qingdao FOCUS MACHINERY Co., Ltd, founded in 1990s, was dedicated to manufacture paper machines and provide production line for paper industry.
Based on leading technologies, experiences and knowhow, we could meet a variety of requirements and offer turn key projects.
We are also one of the subsidiary companies of Goodwill Group Limited who was founded in U.K. Since we built more than 30 successful production lines and exporting lots of machines in South America, Asia, Africa, Europe, etc., more customers desired to visit us personally, not only check capacity but also to see our machines how to work and paper quality made by them, so 15 years ago we built paper factory by machines and production lines we produced and designed.
Our products are sold all over the world, you can rest assured.
