FOCUS Thermal Paper Cutting Machine for ATM POS Plotter Rolls 80x80mm

FOCUS Thermal Paper Cutting Machine for ATM POS Plotter Rolls 80x80mm

  • Highlight

    Thermal paper cutting machine

    ,

    ATM POS roll cutter

    ,

    80x80mm thermal paper slitter

  • Max. Parent Web Width
    900mm
  • Max. Parent Web Diameter
    1000mm
  • Max. Rewinding Diameter
    2.2Kw
  • Thickness Range
    40-400gsm
  • Max. Machine Speed
    200m/min
  • Overall Dimension
    1600*1700*1600mm (1 Ply)
  • Weight
    1900kg
  • Voltage
    3 Phase 220V 60HZ Or 380V 50HZ
  • Machine Type
    Flexo Letterpress Printing Machine
  • Overall Dimension
    4000*1700*1600mm
  • Power Supply
    220V/50Hz
  • Max. Unwinding Diameter
    1000mm
  • Cutting Accuracy
    ±0.1mm
  • Rewind Diameter
    160mm
  • Slitting Accuracy
    ±0.1mm
  • Place of Origin
    China
  • Brand Name
    FOCUS
  • Certification
    SGS, FSC,ISO
  • Model Number
    FM25PSM0412001
  • Minimum Order Quantity
    1

FOCUS Thermal Paper Cutting Machine for ATM POS Plotter Rolls 80x80mm

FOCUS Thermal Paper Cutting Machine for ATM POS Plotter Rolls 80x80mm
Key Specifications
Max. Parent Web Width 900mm
Max. Parent Web Diameter 1000mm
Max. Rewinding Diameter 2.2Kw
Thickness Range 40-400gsm
Max. Machine Speed 200m/min
Overall dimension 1600*1700*1600mm (1 Ply)
Weight 1900kg
Voltage 3 Phase 220V 60HZ or 380V 50HZ
Cutting Accuracy ±0.1mm
Slitting Accuracy ±0.1mm
Product Overview

The FOCUS Thermal Paper Cutting Machine is engineered to handle an array of paper materials, from thermal and NCR paper to fax and ATM paper. It can cut paper with a thickness of up to 250gsm. With its fully automated system, the machine requires minimal operator input—just set the speed and tension, and it manages the rest. Designed for ease of use and high precision, it has gained widespread popularity in international markets for its reliability and efficiency.

FOCUS Thermal Paper Cutting Machine for ATM POS Plotter Rolls 80x80mm 0
Technical Parameters
Max. Parent Web Width 900mm
Max. Parent Web Diameter 1000mm
Max. Rewinding Diameter 200mm
Frequency Inverter Motor 2.2Kw
Thickness Range 40-400gsm
Max. Machine Speed 200m/min
Overall dimension 1600*1700*1600mm (1 Ply)
Weight 1900kg
Voltage 3 Phase 220V 60HZ or 380V 50HZ
FOCUS Thermal Paper Cutting Machine for ATM POS Plotter Rolls 80x80mm 1 FOCUS Thermal Paper Cutting Machine for ATM POS Plotter Rolls 80x80mm 2 FOCUS Thermal Paper Cutting Machine for ATM POS Plotter Rolls 80x80mm 3 FOCUS Thermal Paper Cutting Machine for ATM POS Plotter Rolls 80x80mm 4 FOCUS Thermal Paper Cutting Machine for ATM POS Plotter Rolls 80x80mm 5
About Qingdao FOCUS MACHINERY Co., Ltd.

Qingdao FOCUS MACHINERY Co., Ltd, founded in 1990s, was dedicated to manufacture paper machines and provide production line for paper industry.

Based on leading technologies, experiences and knowhow, we could meet a variety of requirements and offer turn key projects.

We are also one of the subsidiary companies of Goodwill Group Limited who was founded in U.K. Since we built more than 30 successful production lines and exporting lots of machines in South America, Asia, Africa, Europe, etc., more customers desired to visit us personally, not only check capacity but also to see our machines how to work and paper quality made by them, so 15 years ago we built paper factory by machines and production lines we produced and designed.
