Automatic High-Speed Thermal Paper Slitter Machine for 250gsm Rolls
-
Highlight
High-Speed Thermal Paper Slitter
,Automatic Paper Slitting Machine
,250gsm Thermal Roll Slitter
-
Max. Parent Web Width900mm
-
Max. Parent Web Diameter1000mm
-
Max. Rewinding Diameter2.2Kw
-
Thickness Range40-400gsm
-
Max. Machine Speed200m/min
-
Overall Dimension1600*1700*1600mm (1 Ply)
-
Weight1900kg
-
Voltage3 Phase 220V 60HZ Or 380V 50HZ
-
Machine TypeFlexo Letterpress Printing Machine
-
Overall Dimension4000*1700*1600mm
-
Power Supply220V/50Hz
-
Max. Unwinding Diameter1000mm
-
Cutting Accuracy±0.1mm
-
Rewind Diameter160mm
-
Slitting Accuracy±0.1mm
-
Place of OriginChina
-
Brand NameFOCUS
-
CertificationSGS, FSC，ISO
-
Model NumberFM25PSM0412001
-
Minimum Order Quantity1
Automatic High-Speed Thermal Paper Slitter Machine for 250gsm Rolls
| Attribute | Value |
|---|---|
| Max. Parent Web Width | 900mm |
| Max. Parent Web Diameter | 1000mm |
| Max. Rewinding Diameter | 2.2Kw |
| Thickness Range | 40-400gsm |
| Max. Machine Speed | 200m/min |
| Overall dimension | 1600*1700*1600mm (1 Ply) |
| Weight | 1900kg |
| Voltage | 3 Phase 220V 60HZ or 380V 50HZ |
| Machine Type | Flexo Letterpress Printing Machine |
| Cutting Accuracy | ±0.1mm |
| Slitting Accuracy | ±0.1mm |
Designed for high-speed operations, the FOCUS High-Speed Thermal Paper Slitter efficiently slits thermal, NCR, fax, ATM, and self-adhesive label papers. With a capacity of up to 250gsm paper thickness, it is well-suited for high-volume production.
Thanks to its advanced automation, operators only need to set speed and tension, and the machine will automatically manage the slitting process, offering consistent and reliable results. This machine is designed for ease of use and boasts a high level of automation.
All key parameters are fine-tuned and optimized prior to shipment, so the only task for the operator is to input the desired speed and tension values. Once set, the machine takes over, managing all functions automatically and in sync. Its efficiency and simplicity have made it increasingly popular across global markets.
| Item | Specification |
|---|---|
| Max. Parent Web Width | 900mm |
| Max. Parent Web Diameter | 1000mm |
| Max. Rewinding Diameter | 200mm |
| Frequency Inverter Motor | 2.2Kw |
| Thickness Range | 40-400gsm |
| Max. Machine Speed | 200m/min |
| Overall dimension | 1600*1700*1600mm (1 Ply) |
| Weight | 1900kg |
| Voltage | 3 Phase 220V 60HZ or 380V 50HZ |
