7 Ply CB CF CFB Computer Continuous Carbonless Paper Printing

7 Ply CB CF CFB Computer Continuous Carbonless Paper Printing

  • High Light

    CB CF carbonless paper printing

    ,

    CFB carbonless paper printing

    ,

    7 Ply computer continuous paper

  • Material
    100% Vrigin Wood Pulp
  • Brand
    Focus
  • Sample
    Free Sample
  • Image
    Blue Image
  • Color
    Pink, Blue, Yellow, Green, White
  • Size
    9.5*11 Inch
  • Packing
    Sheet And Rells
  • Gram
    55gsm
  • Smoothness
    ≥80 S
  • Opacity
    ≥60 %
  • Density
    0.65-0.83 G/cm3
  • Layer
    1-7 Plys
  • Item
    CB, CFB, CF
  • Brightness
    ≥90 %
  • TSI(MD)
    ≥55N.m/g
  • Origin
    China
  • Place of Origin
    China
  • Brand Name
    FOCUS
  • Certification
    SGS
  • Model Number
    computer form
  • Minimum Order Quantity
    15 tons
  • Price
    1500usd per ton
  • Packaging Details
    pallet
  • Delivery Time
    30-45 working days
  • Payment Terms
    D/P, T/T, L/C, D/A
  • Supply Ability
    6000 tons per month

7 Ply CB CF CFB Computer Continuous Carbonless Paper Printing

7ply CB/CF/CFB Continuous Computer Carbonless Paper Compatible Matrix Printers





INTRODUCTION



7ply CB/CF/CFB Continuous Computer Carbonless Paper Compatible Matrix Printers



1. Evenly coated and high printing density.

2. Blue or black impression color customized available.

3. Refinefly cut, no paper jam when printing.



TECHNICAL DATA

NCR PAPER TECHNOLOGY SPECIFICATION TEST REPORT



Grades Blue/Black Image



Regular basis weight (gsm)



CB white: 55

CFB colored: 50

CF colored: 55



Basis weight variation



±5%



Caliper Variation (CD)

≤5μm for 50GSM or less GSM

≤7µm for 50GSM or greater GSM



Paper Density



0.70-0.85 g/cm3



Opacity



≥65%



Smoothness (CF side)



≥80s



Whiteness



≥90%



Thickness



65μm CB 60μm CFB

65μm CF



Chromatic deviation



≤2.0% (coated side for tinted grades)



Curls



≤12 mm



Imaging Sensitivity (6 ply prints)



ΔE≥40% ΔD≥40%



Surface strength (medium viscosity printing ink)



≥0.55 m/s (printing side)



Light resistance (residual ΔE after 144 hrs)



≥50%



Friction resistance (Δ E)



≤5%



TSI (MD)



≥60 N.m/g



Surface PH



6.0-9.0



Moisture on delivery



6.5% ± 2.0%









HOW CARBONLESS PAPER WORKS?



When writing on the top of multiple ply NCR documents, the pressure from the writing instrument causes the microcapsules (on the back of CB & CFB) break, the contains will react with the developer (on the front of CFB & CF) and finally realize auto copy.

7 Ply CB CF CFB Computer Continuous Carbonless Paper Printing 0







Roll
Base gsm CB 55gsm, CFB 50gsm, CF 55gsm
Image Black/Blue
Color White/Pink/Yellow/Blue Green
Core Size 76mm
Paper Width Customized (241,305,482,457,600mm, etc)
Regular Length 6000m/12000m





Sheet
Base gsm CB 55gsm, CFB 50gsm, CF 55gsm
Image Black/Blue
Color White/Pink/Yellow/Blue Green
Regular Size

Customized

(61x86,70x100,65x100cm,69x89cm,67x87cm,65x92cm,72x92cm, etc)



Commercial Bill
Base gsm CB 55gsm, CFB 50gsm, CF 55gsm
Image Black/Blue
Color White/Pink/Yellow/Blue Green
Regular Size

Customized

(9.5*11 inches, 8.5*11 inches, etc)






7 Ply CB CF CFB Computer Continuous Carbonless Paper Printing 1




COMPANY INFORMATION
7 Ply CB CF CFB Computer Continuous Carbonless Paper Printing 2

HOW IS CARBONLESS PAPER PRODUCED

7 Ply CB CF CFB Computer Continuous Carbonless Paper Printing 3
7 Ply CB CF CFB Computer Continuous Carbonless Paper Printing 4



PACKAGING AND LOADING OF OUR CARBONLESS PAPER



7 Ply CB CF CFB Computer Continuous Carbonless Paper Printing 57 Ply CB CF CFB Computer Continuous Carbonless Paper Printing 6

7 Ply CB CF CFB Computer Continuous Carbonless Paper Printing 7

CERTIFICATE OF OUR CARBONLESS PAPER

SGS, BV, FSC, ISO




7 Ply CB CF CFB Computer Continuous Carbonless Paper Printing 8



FOCUS attends more than 15 exhibitions of carbonless paper/thermal paper/paper machine every year all over the world to meet and service clients face to face.
