250g 300mm Paper Coating Machine 6T Paper Production Machine

250g 300mm Paper Coating Machine 6T Paper Production Machine

  • High Light

    300mm 250g Paper Coating Machines

    ,

    300mm Paper Coating Machine 250g

    ,

    6T paper production machines 250g

  • Certification
    CE, ISO9001, BV, ISO
  • Machine Width
    1400mm
  • Base Paper Width
    <1400mm
  • Base Paper Weight
    40-250 G/m2
  • Size
    80000*7000*7000
  • Weight
    6 Tons
  • Finished Product
    Thermal Paper
  • Warranty
    2 Years
  • Packing
    Wooden Box
  • Base Paper Moisture
    5-7%
  • Voltage
    380V, 220V
  • Speed
    300m/min
  • Function
    Paper Coating
  • Rewind Diameter
    1400MM
  • Unwinding Diameter
    1300mm
  • Service
    Engineers Available
  • Product Name
    Thermal Paper Coating Machine
  • Place of Origin
    China
  • Brand Name
    FOCUS
  • Model Number
    1400mm
  • Minimum Order Quantity
    1 set
  • Price
    500000usd per set
  • Packaging Details
    wooden box
  • Delivery Time
    60-90 working days
  • Payment Terms
    L/C, D/A, D/P, T/T
  • Supply Ability
    10 sets per month

250g 300mm Paper Coating Machine 6T Paper Production Machine

1400/300mm FOCUS Brand Thermal Paper Double-side Coating Machinee


DESCRIPTION

1400/300mm FOCUS Brand Thermal Paper Double-side Coating Machine



Focus brand 1400/300 Thermal paper coating production line is one of the pioneering production line in the thermal paper industry, which can achieve the two times coating at the same time. Especially suitable for Thermal paper production with the features of high speed, high efficiency of production, low energy consumption, stable performance of equipment, low consumption of base paper, and high yield.



TECHNICAL DATA



Items Parameters
Max. Parent Web Width 1400mm
Max. Parent Web Diameter 1300mm
Max. Rewinding Diameter 1400mm
Compress air pressure 0.6MPa
Base paper weight Range 40-250gsm
Max. Machine Speed 00m/min
Overall dimension 80000*7000*7000mm
Weight 6000kg
Voltage 220V, 380V




GENERAL STRUCTURE

Double working position roll-over unwinding frame ( Automatic splicing device)→ No.1 Blade Combined measuring rod coater→hot air dry system (4mx3)→ Draw roll →1# Two roll calender→2# Blade Combined measuring rod coater→hot air dry system (4mx4)→ Draw roll→2# Two roll calender →3# Blade Combined measuring rod coater→ hot air dry system(4mx3)→Back water coater→Hot air dry system (4mx1) →φ1500 finishing cylinder (3 pieces)→Cold water roll→3# Two roll calendar→ Automatic splicing device→ Double working position turn over rewinding frame (automatic correction)

250g 300mm Paper Coating Machine 6T Paper Production Machine 0









APPLICATION

Thermal paper after coating

Thermal Paper Jumbo Roll

Thermal Paper POS Roll

Thermal Paper Label Roll

250g 300mm Paper Coating Machine 6T Paper Production Machine 1250g 300mm Paper Coating Machine 6T Paper Production Machine 2250g 300mm Paper Coating Machine 6T Paper Production Machine 3

250g 300mm Paper Coating Machine 6T Paper Production Machine 4
250g 300mm Paper Coating Machine 6T Paper Production Machine 5

250g 300mm Paper Coating Machine 6T Paper Production Machine 6250g 300mm Paper Coating Machine 6T Paper Production Machine 7

MACHINE PACKING AND TEST RUNNING OF THERMAL PAPER COATING MACHINE

Packaging Details
The normal package is wooden box. The wooden box will be fumigated. If container is too tigher, we will use pe film for packing or pack it according to customers special request

250g 300mm Paper Coating Machine 6T Paper Production Machine 8



250g 300mm Paper Coating Machine 6T Paper Production Machine 9







250g 300mm Paper Coating Machine 6T Paper Production Machine 10
250g 300mm Paper Coating Machine 6T Paper Production Machine 11

COMPANY INFORMATION
250g 300mm Paper Coating Machine 6T Paper Production Machine 12

SUCCESSFUL MACHINE PROJECTS

250g 300mm Paper Coating Machine 6T Paper Production Machine 13250g 300mm Paper Coating Machine 6T Paper Production Machine 14



THERMAL PAPER COATING MACHINE PRODUCTION PROCESS

250g 300mm Paper Coating Machine 6T Paper Production Machine 15
250g 300mm Paper Coating Machine 6T Paper Production Machine 16

CUSTOMER FEEDBACK

250g 300mm Paper Coating Machine 6T Paper Production Machine 17
CERTIFICATE
250g 300mm Paper Coating Machine 6T Paper Production Machine 18

FOCUS attends more than 15 exhibitions of carbonless paper/thermal paper/paper coating machine every year all over the world to meet and service clients face to face.
250g 300mm Paper Coating Machine 6T Paper Production Machine 19


Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
