70GSM 1045mm Paper Converting Machine Paper Roll Slitting Machine 375m/Min

70GSM 1045mm Paper Converting Machine Paper Roll Slitting Machine 375m/Min

  • High Light

    375m/min 70GSM Paper Converting Machine

    ,

    1045mm Paper Converting Machine 375m/min

    ,

    paper roll slitting machine 375m/min

  • Gross Width
    1065mm
  • Net Width
    1045mm
  • Number Of Cuts
    5 Rolls -5 Cuts—A4 (short Side 210mm)
  • Diameter Of Paper Shaft
    400mm-1200mm;
  • Diameter Paper Core
    3″(76.2mm) And 6″(152.4mm)
  • Cutting Length
    The Machine Is Designed To Process A4 Paper, And Its Cutting Length Is 297mm On The Long Side Of A4 Paper
  • Paper Grade
    Copy Paper, Writing Paper, Double Offset Paper And Other Advanced Papers. Weight Range Of Paper: 60-100g/m2
  • Height Of Ream Paper
    ≤65mm
  • Design Speed
    375m/min Max
  • Production Speed
    200-260m/min (depending On Paper Type)
  • Cutting Times
    650 Times/min
  • Ream Paper Discharge Weekly
    6-7 Times/min (28-35 Reams/min)
  • Paper Cutting Conditions
    1. The Speed Remains Unchanged 2. The Paper Shaft Cannot Be Broken 3. Qualified Paper Is Required
  • Drive
    AC Variable Frequency Stepless Speed Regulation
  • Main Power Supply
    3-phase 4-wire 380V 50HZ
  • Voltage
    220V AC/22V DC
  • Air Pressure
    0.6-0.8 Mpa
  • Equipment Dimensions
    Length × Width× Height 20000 (mm) × 2960 (mm)× 2100 (mm)
  • Place of Origin
    China
  • Brand Name
    FOCUS
  • Certification
    SGS
  • Model Number
    A4-35 model
  • Minimum Order Quantity
    1 set
  • Price
    1500000 usd per set
  • Packaging Details
    wooden box
  • Delivery Time
    20-50 days
  • Payment Terms
    L/C, D/A, D/P, T/T
  • Supply Ability
    1 sets per month

70GSM 1045mm Paper Converting Machine Paper Roll Slitting Machine 375m/Min

A4-35 Model Hight Speed 5 Cuts 5rolls Copy Paper Roll Slititng Machine Paper Converting Machine



This machine is designed for horizontal and vertical cutting paper rolling materials to A4, A3, A2,and other sizes etc.

5rolls&5cuts(A4-35 model)hight speed copy paper roll slititng machine+Packing machine + cartoning machine + tapping machine + palletizing.



Main composition of Sheet Cutter

1. Shaftless ground lifting and upper paper support system control------------- Five sets

2. Advanced tension control system ------------------------------------------------- Five sets

3. Anti-warping mechanism -----------------------------------------------------------Five sets

4. Slitting and slitting upper and lower knife sets --------------------------------- Six sets

5. Synchronous cross-cutting of upper and lower tool sets ----------------------- One set

6. High-speed paper feeding system ------------------------------------------------- One set

7. Low-speed paper conveying system --------------------------------------------- One set

8. Automatic waste paper discharge device ---------------------------------------- One set

9. 2D oscillating whole paper, pneumatic lifting paper collecting device ------One set

10. PLC paper counting device ------------------------------------------------------ One set

11. Equipment for discharging paper vertically and horizontally ----------------One set

12. PLC fault alarm and shutdown system and PLC control equipment -------- One set



Technical Data



Main parameter
Working width: gross width: 1056mm; net width: 1050mm
Number of cuts: 5 rolls and 5 cuts—A4 short side 210mm
Paper shaft diameter: max1200mm; min400mm
Paper core diameter: 3″(76.2mm) and 6″(152.4mm)
Paper grade: advanced copy paper, advanced writing paper, advanced double offset paper and other advanced papers. Paper weight range: 60-100g/m2×5 sheets
Cutting length: The cutting machine is designed to process A4 paper, and its cutting length is 297mm on the long side of A4 paper.
Ream paper count: 0-500 pages,
Ream paper height (max) 65mm
Design speed: max 375m/min
775 times/min
Weekly discharge of paper: 8/min
Production speed: 200-260m/min (depending on different paper)
Cutting times: 650 times/min
Ream paper discharge weekly: 6-7 times/min (28-35 reams/min)
Paper cutting load: (max) 400g/m2 (4x100g/m2)
Paper cutting accuracy: allowable error ±0.2mm
Paper cutting conditions: 1. The speed remains unchanged 2. The paper shaft cannot be broken 3. Qualified paper is required
Drive: AC variable frequency stepless speed regulation
Main power supply: 3-phase 4-wire 380V 50HZ
Control voltage: 220V AC/22V DC
Installed capacity: (approm) 25KW
Compressed air consumption: (approm) 300NL/min
Compressed air pressure: 0.6-0.8 mpa
Equipment dimensions: length 20000 (mm) × width 2960 (mm) × height 2100 (mm)
Total weight: 19T
